6308ZZ
Deep groove ball bearing 6308ZZ
Deep groove ball bearing, 40 mm bore, 90 mm outside diameter and 23 mm width. Made to ISO boundary dimensions for interchange with common industry designations.
Highlights
- 100% dimensional inspection before packing
- C2 / C3 clearance options on request
- OEM or neutral packaging
Applications
- Electric motors
- Water pumps
- Conveyor idlers
- Agricultural machinery
Details
The 6308ZZ is a deep groove ball bearing: 40 mm bore, 90 mm outside diameter and 23 mm width.
Supplied to ISO boundary dimensions so it is dimensionally interchangeable with the corresponding industry designation. Quantity pricing, clearance and packaging options are confirmed with your quote — add the model to the enquiry list to start.
Specifications
| Dimensions | |
|---|---|
| Bore (d) | 40 mm |
| Outside diameter (D) | 90 mm |
| Width (B) | 23 mm |
| Seal | |
| Seal type | ZZ metal shields |
